This article was first published on SearchServerVirtualization.TechTarget.com.

Deploying virtualization into a production data center can provide an interesting mix of pros and cons. By consolidating workloads onto fewer server, physical management is simplified. But what about managing the VMs? While storage solutions can provide much-needed flexibility, it’s still up to datacenter administrators to determine their needs and develop appropriate solutions. In this article, I’ll present storage-related considerations for datacenter administrators.

Estimating Storage Capacity Requirements

Virtual machines generally require a large amount of storage. The good news is that this can, in some cases, improve storage utilization. Since direct-attached storage is not confined to a per-server basis (which often results in a lot of unused space), using centralized storage arrays can help. There’s also a countering effect, however: Since the expansion of virtual disk files is difficult to predict, you’ll need to leave some unallocated space for expansion. Storage solutions that provide for over-committing space (sometimes referred to as “soft-allocation”) and for dynamically resizing arrays can significantly simplify management.

• To add up the storage requirements, you should consider the following:
• The sum of the sizes of all “live” virtual disk files
• Expansion predictions for virtual disk files
• State-related disk files such as those used for suspending virtual machines and maintaining point-in-time snapshots
• Space required for backups of virtual machines

All of this can be a tall order, but hopefully the overall configuration is no more complicated than that of managing multiple physical machines.

Placing Virtual Workloads

One of the best ways to reduce disk contention and improve overall performance is to profile virtual workloads to determine their requirements. Performance statistics help determine the number, size, and type of IO operations. Table 1 provides an example.

Table 1: Assigning workloads to storage arrays based on their performance requirements

In the provided example, the VMs are assigned to separate storage arrays to minimize contention. By combining VMs with “compatible” storage requirements on the same server, administrators can better distribute load and increase scalability.

Selecting Storage Methods

When planning to deploy new virtual machines, datacenter administrators have several different options. The first is to use local server storage. Fault-tolerant disk arrays that are directly-attached to a physical server can be easy to configure. For smaller virtualization deployments, this approach makes sense. However, when capacity and performance requirements grow, adding more physical disks to each server can lead to management problems. For example, arrays are typically managed independently, leading to wasted disk space and requiring administrative effort.

That’s where network-based storage comes in. By using centralized, network-based storage arrays, organizations can support many host servers using the same infrastructure. While support for technologies varies based on the virtualization platform, NAS, iSCSI, and SAN-based storage are the most common. NAS devices use block-level IO and are typically used as file servers. They can be used to store VM configuration and hard disk files. However, latency and competition for physical disk resources can be significant.

SAN and iSCSI storage solutions perform block-level IO operations, providing raw access to storage resources. Through the use of redundant connections and multi-pathing, they can provide the highest levels of performance, lowest latency, and simplified management.

In order to determine the most appropriate option, datacenter managers should consider workload requirements for each host server and its associated guest OS’s. Details include the number and types of applications that will be running, and their storage and performance requirements. The sum of this information can help determine whether local or network-based storage is most appropriate.

Monitoring Storage Resources

CPU and memory-related statistics are often monitoring for all physical and virtual workloads. In addition to this information, disk-related performance should be measured. Statistics collected at the host server level will provide an aggregate view of disk activity and whether storage resources are meeting requirements. Guest-level monitoring can help administrators drill-down into the details of which workloads are generating the most activity. While the specific statistics that can be collected will vary across operating systems the types of information that should be monitoring include:

• IO per Second (IOPs): This statistic refers to the number of disk-related transactions that are occurring at a given instant. IOPs are often used as the first guideline for determining overall storage requirements.
• Storage IO Utilization: This statistic refers to the percentage of total IO bandwidth that is being consumed at a given point in time. High levels of utilization can indicate the need to upgrade or move VMs.
• Paging operations: Memory-starved VMs can generate significant IO traffic due to paging to disk. Adding or reconfiguring memory settings can help improve performance.
• Disk queue length: The number of IO operations that are pending. A consistently high number will indicate that storage resources are creating a performance bottleneck.
• Storage Allocation: Ideally, administrators will be able to monitor the current amount of physical storage space that is actually in use for all virtual hard disks. The goal is to proactively rearrange or reconfigure VMs to avoid over-allocation.

VM disk-related statistics will change over time. Therefore, the use of automated monitoring tools that can generate reports and alerts are an important component of any virtualizations storage environment.

Summary

Managing storage capacity and performance should be high on the list of responsibilities for datacenter administrators. Virtual machines can easily be constrained by disk-related bottlenecks, causing slow response times or even downtime. By making smart VM placement decisions and monitoring storage resources, many of these potential bottlenecks can be overcome. Above all, it’s important for datacenter administrators to work together with storage managers to ensure that business and technical goals remain aligned over time.

This article was first published on SearchServerVirtualization.TechTarget.com.

It’s common for new technology to require changes in all areas of an organization’s overall infrastructure. Virtualization is no exception. While many administrators often focus on CPU and memory constraints, storage-related performance is also a very common bottleneck. In some ways, virtual machines can be managed like physical ones. After all, each VM runs its own operating systems, applications, and services. But there are also numerous additional considerations that must be taken into account when designing a storage infrastructure. By understanding the unique needs of virtual machines, storage managers can build a reliable and scalable data center infrastructure to support their VMs.

Analyzing Disk Performance Requirements

For many types of applications, the primary consideration around which the storage infrastructure is designed is based on I/O operations per second (IOPS). IOPS refer to the number of read and write operations that are performed, but do not always capture the whole picture. Additional considerations include the type of activity. For example, since virtual disks that are stored on network-based storage arrays must support guest OS disk activity, the average I/O request size tends to be small. Additionally, I/O requests are frequent and often random in nature. Paging can also create a lot of traffic on memory-constrained host servers. There are also other considerations that will be workload-specific. For example, it’s also good to measure the percentage of read vs. write operations when designing the infrastructure.

Now, multiply all of these statistics by the number of VMs that are being supported on a single storage device, and you are faced with the very real potential for large traffic jams. The solution? Optimize the storage solution for supporting many, small, and non-sequential IO operations. And, most importantly, distribute VMs based on their levels and types of disk utilization. Performance monitoring can help generate the information you need.

Considering Network-Based Storage Approaches

Many environments already use a combination of NAS, SAN, and iSCSI-based store to support their physical servers. These methods can still be used for hosting virtual machines, as most virtualization platforms provide support for them. For example, SAN- or iSCSI-based volumes that are attached to a physical host server can be used to store virtual machine configuration files, virtual hard disks, and related data. It is important to note that, by default, the storage is attached to the host and not to the guest VM. Storage managers should keep track of which VMs reside on which physical volumes for backup and management purposes.

In addition to providing storage at the host-level, guest operating systems (depending on their capabilities) can take advantage of NAS and iSCSI-based storage. With this approach, VMs can directly connect to network-based storage. A potential drawback, however, is that guest operating systems can be very sensitive to latency, and even relatively small delays can lead to guest OS crashes or file system corruption.

Evaluating Useful Storage Features

As organizations place multiple mission-critical workloads on the same servers through the use of virtualization, they can use various storage features to improve reliability, availability and performance. Implementing RAID-based striping across arrays of many disks can help significantly improve performance. The array’s block size should be matched to the most common size of I/O operations. However, more disks means more chances for failures. So, features such as multiple parity drives and hot standby drives are a must.

Fault tolerance can be implemented through the use of multi-pathing for storage connections. For NAS and iSCSI solutions, storage managers should look into having multiple physical network connections and implementing fail-over and load-balancing features by using network adapter teaming. Finally, it’s a good idea for host servers to have dedicated network connections to their storage arrays. While you can often get by with shared connections in low-utilization scenarios, the load placed by virtual machines can be significant and can increase latency.

Planning for Backups

Storage administrators will have the need to backup many of their virtual machines. Apart from allocating the necessary storage space, it is necessary to develop a method for dealing with exclusively-locked virtual disk files. There are two main approaches:

• Guest-Level Backups: In this approach, VMs are treated like physical machines. Generally, you would install backup agents within VMs, define backup sources and destinations, and then let them go to work. The benefit of this approach is that only important data is backed up (thereby reducing required storage space). However, your backup solution must be able to support all potential guest OS’s and versions. And, the complete recovery process can involve many steps, including reinstalling and reconfiguring the guest OS.
• Host-Level Backups: Virtual machines are conveniently packaged into a few important files. Generally, this includes the VM configuration file and virtual disks. You can simply copy these files to another location. The most compatible approach involves stopping or pausing the VM, copying the necessary files, and then restarting the VM. The issue, however, is that this can require downtime. Numerous first- and third-party solutions are able to backup VMs while they’re “hot”, thereby eliminating service interruptions. Regardless of the method used, replacing a failed or lost VM is easy – simple restore the necessary files to the same or another host server and you should be ready to go. The biggest drawback of host-level backups is in the area of storage requirements. You’re going to be allocating a ton of space for the guest OS’s, applications, and data you’ll be storing.

Storage solutions options such as the ability to perform snapshot-based backups can be useful. However, storage administrators should thoroughly test the solution and should look for explicitly-stated virtualization support from their vendors. Remember, backups must be consistent to a point in time, and non-virtualization-aware solutions might neglect to flush information stored in the guest OS’s cache.

Summary

By understanding and planning for the storage-related needs of virtual machines, storage administrators can help their virtual environments scale and keep pace with demand. While some of the requirements are somewhat new, many involve utilizing the same storage best practices that are used for physical machines. Overall, it’s important to measure performance statistics and to consider storage space and performance when designing a storage infrastructure for VMs.
